Blondel ICML’20 Fast Differentiable Sorting and Ranking¶

# https://github.com/google-research/fast-soft-sort/tree/master

import numpy as np
from scipy import special

from numba import njit
def njit(func):
    return func

@njit
def isotonic_l2_pav(y, sol):
  """Solves an isotonic regression problem using PAV.

  Formally, it solves argmin_{v_1 >= ... >= v_n} 0.5 ||v - y||^2.

  Args:
    y: input to isotonic regression, a 1d-array.
    sol: where to write the solution, an array of the same size as y.
  """
  n = y.shape[0]
  target = np.arange(n)
  c = np.ones(n)
  sums = np.zeros(n)

  # target describes a list of blocks.  At any time, if [i..j] (inclusive) is
  # an active block, then target[i] := j and target[j] := i.

  for i in range(n):
    sol[i] = y[i]
    sums[i] = y[i]

  i = 0
  while i < n:
    k = target[i] + 1
    if k == n:
      break
    if sol[i] > sol[k]:
      i = k
      continue
    sum_y = sums[i]
    sum_c = c[i]
    while True:
      # We are within an increasing subsequence.
      prev_y = sol[k]
      sum_y += sums[k]
      sum_c += c[k]
      k = target[k] + 1
      if k == n or prev_y > sol[k]:
        # Non-singleton increasing subsequence is finished,
        # update first entry.
        sol[i] = sum_y / sum_c
        sums[i] = sum_y
        c[i] = sum_c
        target[i] = k - 1
        target[k - 1] = i
        if i > 0:
          # Backtrack if we can.  This makes the algorithm
          # single-pass and ensures O(n) complexity.
          i = target[i - 1]
        # Otherwise, restart from the same point.
        break

  # Reconstruct the solution.
  i = 0
  while i < n:
    k = target[i] + 1
    sol[i + 1 : k] = sol[i]
    i = k

import numpy as np
from scipy import special


def isotonic_l2(input_s, input_w=None):
  if input_w is None:
    input_w = np.arange(len(input_s))[::-1] + 1
  input_w = input_w.astype(input_s.dtype)
  solution = np.zeros_like(input_s)
  isotonic_l2_pav(input_s - input_w, solution)
  return solution



def _partition(solution, eps=1e-9):
  """Returns partition corresponding to solution."""
  # pylint: disable=g-explicit-length-test
  if len(solution) == 0:
    return []

  sizes = [1]

  for i in range(1, len(solution)):
    if abs(solution[i] - solution[i - 1]) > eps:
      sizes.append(0)
    sizes[-1] += 1

  return sizes


def _check_regularization(regularization):
  if regularization not in ("l2", "kl"):
    raise ValueError("'regularization' should be either 'l2' or 'kl' "
                     "but got %s." % str(regularization))


class _Differentiable(object):
  """Base class for differentiable operators."""

  def jacobian(self):
    """Computes Jacobian."""
    identity = np.eye(self.size)
    return np.array([self.jvp(identity[i]) for i in range(len(identity))]).T

  @property
  def size(self):
    raise NotImplementedError

  def compute(self):
    """Computes the desired quantity."""
    raise NotImplementedError

  def jvp(self, vector):
    """Computes Jacobian vector product."""
    raise NotImplementedError

  def vjp(self, vector):
    """Computes vector Jacobian product."""
    raise NotImplementedError


class Isotonic(_Differentiable):
  """Isotonic optimization."""

  def __init__(self, input_s, input_w, regularization="l2"):
    self.input_s = input_s
    self.input_w = input_w
    _check_regularization(regularization)
    self.regularization = regularization
    self.solution_ = None

  @property
  def size(self):
    return len(self.input_s)

  def compute(self):

    if self.regularization == "l2":
      self.solution_ = isotonic_l2(self.input_s, self.input_w)
    else:
      self.solution_ = isotonic_kl(self.input_s, self.input_w)
    return self.solution_

  def _check_computed(self):
    if self.solution_ is None:
      raise RuntimeError("Need to run compute() first.")

  def jvp(self, vector):
    self._check_computed()
    start = 0
    return_value = np.zeros_like(self.solution_)
    for size in _partition(self.solution_):
      end = start + size
      if self.regularization == "l2":
        val = np.mean(vector[start:end])
      else:
        val = np.dot(special.softmax(self.input_s[start:end]),
                     vector[start:end])
      return_value[start:end] = val
      start = end
    return return_value

  def vjp(self, vector):
    start = 0
    return_value = np.zeros_like(self.solution_)
    for size in _partition(self.solution_):
      end = start + size
      if self.regularization == "l2":
        val = 1. / size
      else:
        val = special.softmax(self.input_s[start:end])
      return_value[start:end] = val * np.sum(vector[start:end])
      start = end
    return return_value


def _inv_permutation(permutation):
  """Returns inverse permutation of 'permutation'."""
  inv_permutation = np.zeros(len(permutation), dtype=int)
  inv_permutation[permutation] = np.arange(len(permutation))
  return inv_permutation


class Projection(_Differentiable):
  """Computes projection onto the permutahedron P(w)."""

  def __init__(self, input_theta, input_w=None, regularization="l2"):
    if input_w is None:
      input_w = np.arange(len(input_theta))[::-1] + 1
    self.input_theta = np.asarray(input_theta)
    self.input_w = np.asarray(input_w)
    _check_regularization(regularization)
    self.regularization = regularization
    self.isotonic = None

  def _check_computed(self):
    if self.isotonic_ is None:
      raise ValueError("Need to run compute() first.")

  @property
  def size(self):
    return len(self.input_theta)

  def compute(self):
    self.permutation = np.argsort(self.input_theta)[::-1]
    input_s = self.input_theta[self.permutation]

    self.isotonic_ = Isotonic(input_s, self.input_w, self.regularization)
    dual_sol = self.isotonic_.compute()
    primal_sol = input_s - dual_sol

    self.inv_permutation = _inv_permutation(self.permutation)
    return primal_sol[self.inv_permutation]

  def jvp(self, vector):
    self._check_computed()
    ret = vector.copy()
    ret -= self.isotonic_.jvp(vector[self.permutation])[self.inv_permutation]
    return ret

  def vjp(self, vector):
    self._check_computed()
    ret = vector.copy()
    ret -= self.isotonic_.vjp(vector[self.permutation])[self.inv_permutation]
    return ret


def _check_direction(direction):
  if direction not in ("ASCENDING", "DESCENDING"):
    raise ValueError("direction should be either 'ASCENDING' or 'DESCENDING'")


class SoftRank(_Differentiable):
  """Soft ranking."""

  def __init__(self, values, direction="ASCENDING",
               regularization_strength=1.0, regularization="l2"):
    self.values = np.asarray(values)
    self.input_w = np.arange(len(values))[::-1] + 1
    _check_direction(direction)
    sign = 1 if direction == "ASCENDING" else -1
    self.scale = sign / regularization_strength
    _check_regularization(regularization)
    self.regularization = regularization
    self.projection_ = None

  @property
  def size(self):
    return len(self.values)

  def _check_computed(self):
    if self.projection_ is None:
      raise ValueError("Need to run compute() first.")

  def compute(self):
    if self.regularization == "kl":
      self.projection_ = Projection(
          self.values * self.scale,
          np.log(self.input_w),
          regularization=self.regularization)
      self.factor = np.exp(self.projection_.compute())
      return self.factor
    else:
      self.projection_ = Projection(
          self.values * self.scale, self.input_w,
          regularization=self.regularization)
      self.factor = 1.0
      return self.projection_.compute()

  def jvp(self, vector):
    self._check_computed()
    return self.factor * self.projection_.jvp(vector) * self.scale

  def vjp(self, vector):
    self._check_computed()
    return self.projection_.vjp(self.factor * vector) * self.scale


class SoftSort(_Differentiable):
  """Soft sorting."""

  def __init__(self, values, direction="ASCENDING",
               regularization_strength=1.0, regularization="l2"):
    self.values = np.asarray(values)
    _check_direction(direction)
    self.sign = 1 if direction == "DESCENDING" else -1
    self.regularization_strength = regularization_strength
    _check_regularization(regularization)
    self.regularization = regularization
    self.isotonic_ = None

  @property
  def size(self):
    return len(self.values)

  def _check_computed(self):
    if self.isotonic_ is None:
      raise ValueError("Need to run compute() first.")

  def compute(self):
    size = len(self.values)
    input_w = np.arange(1, size + 1)[::-1] / self.regularization_strength
    values = self.sign * self.values
    self.permutation_ = np.argsort(values)[::-1]
    s = values[self.permutation_]

    self.isotonic_ = Isotonic(input_w, s, regularization=self.regularization)
    res = self.isotonic_.compute()

    # We set s as the first argument as we want the derivatives w.r.t. s.
    self.isotonic_.s = s
    return self.sign * (input_w - res)

  def jvp(self, vector):
    self._check_computed()
    return self.isotonic_.jvp(vector[self.permutation_])

  def vjp(self, vector):
    self._check_computed()
    inv_permutation = _inv_permutation(self.permutation_)
    return self.isotonic_.vjp(vector)[inv_permutation]


class Sort(_Differentiable):
  """Hard sorting."""

  def __init__(self, values, direction="ASCENDING"):
    _check_direction(direction)
    self.values = np.asarray(values)
    self.sign = 1 if direction == "DESCENDING" else -1
    self.permutation_ = None

  @property
  def size(self):
    return len(self.values)

  def _check_computed(self):
    if self.permutation_ is None:
      raise ValueError("Need to run compute() first.")

  def compute(self):
    self.permutation_ = np.argsort(self.sign * self.values)[::-1]
    return self.values[self.permutation_]

  def jvp(self, vector):
    self._check_computed()
    return vector[self.permutation_]

  def vjp(self, vector):
    self._check_computed()
    inv_permutation = _inv_permutation(self.permutation_)
    return vector[inv_permutation]


# Small utility functions for the case when we just want the forward
# computation.


def soft_rank(values, direction="ASCENDING", regularization_strength=1.0,
              regularization="l2"):
  r"""Soft rank the given values.

  The regularization strength determines how close are the returned values
  to the actual ranks.

  Args:
    values: A 1d-array holding the numbers to be ranked.
    direction: Either 'ASCENDING' or 'DESCENDING'.
    regularization_strength: The regularization strength to be used. The smaller
    this number, the closer the values to the true ranks.
    regularization: Which regularization method to use. It
      must be set to one of ("l2", "kl", "log_kl").
  Returns:
    A 1d-array, soft-ranked.
  """
  return SoftRank(values, regularization_strength=regularization_strength,
                  direction=direction, regularization=regularization).compute()


def soft_sort(values, direction="ASCENDING", regularization_strength=1.0,
              regularization="l2"):
  r"""Soft sort the given values.

  Args:
    values: A 1d-array holding the numbers to be sorted.
    direction: Either 'ASCENDING' or 'DESCENDING'.
    regularization_strength: The regularization strength to be used. The smaller
    this number, the closer the values to the true sorted values.
    regularization: Which regularization method to use. It
      must be set to one of ("l2", "log_kl").
  Returns:
    A 1d-array, soft-sorted.
  """
  return SoftSort(values, regularization_strength=regularization_strength,
                  direction=direction, regularization=regularization).compute()

x = [6.5, 0.4, 1.5, 3.8,]
print("sort(x) =", soft_sort(x, regularization_strength=0.1))
print("rank(x) =", soft_rank(x))
